An automated drilling section based on a CNC drilling center KD-612KHSA with automatic loading and unloading system is designed for high-precision drilling of blind and through holes in the planes and ends of furniture parts in the through mode, according to a given drilling map. This complex allows you to eliminate the human factor as much as possible and speed up the work of the additive section. This flexible solution will reduce personnel costs. Thanks to the automatic positioning system, processing accuracy will increase, and the intelligent loading/unloading system will increase productivity.
The line includes:
- Drilling machine KD-612KHSA.
- Automatic loader KHG-232.
- Automatic unloader KHG-932.
- Gantry autoloading and autounloading.
- Algorithm for working with different orders during unloading.
- Simultaneous automatic loading/unloading of two parts.
- Possibility of manual loading.
- High productivity - two parts per minute.
- The length of the workpiece during automatic loading is 250-2800 mm.
- The length of the workpiece when loading manually is 250-2400 mm.
- The maximum width of automatic loading is 130-1200 mm.
- The maximum width for manual loading is 100-1200 mm.
- Drilling workpieces from 6 sides.
- Milling from the top and bottom of the workpiece.
- Grooving saw.
- Barcode scanning system at the entrance.
- Integration with any modern automatic systems.
- Powerful and reliable conveyor drives.
- Visual inspection system and condition monitoring.
- Ability to work with optimizer programs with drilling maps.
- Fencing around the perimeter of the work area.
A control panel with a vision system - an autonomous smart camera manufactured by DATALOGIC, mounted on a bracket, automatically scans all passing barcodes.
There are 3 drilling groups installed on the machine: 12 - horizontal spindles, 35 - vertical spindles (26 - from above, 9 - from below). As standard, 2 milling units (3.5 kW) and a grooving saw are installed.
Minimum distance when drilling with two heads for:
- Vertical holes - 64 mm.
- Horizontal holes - 128 mm.
The machine is designed for use in automatic mode with the possibility of embedding up to 3 machines in a line.
The machine can process two panels at the same time, both top and bottom, within one working cycle, thanks to the possibility of drilling from 6 sides.
2 milling spindles: upper - 5.5 kW, lower - 3.5 kW, 18000 rpm (top and bottom) for cutting straight and curved grooves.
Grooving unit with a saw (disk diameter 120 mm).
Ability to work with all popular programs for optimizing drilling maps.
During the development of the machine, the maximum allowable loads and requirements for the design of the machine were calculated and modeled. The welded frame is tempered to relieve all internal stresses in the material, then it is processed on high-precision CNC equipment.
The discharge conveyor is equipped with belt drives and motion sensors.
The positioning of the workpiece on the machine is carried out thanks to the automatic lateral alignment. After reading the barcode, the side aligner moves as close as possible to the dimensions of the part. The workpiece rests on the zero point along the X axis, and the side leveler positions it along the Y axis. Then two pneumatic grippers take the workpiece into the working area of the machine for further processing.
The powerful vertical clamp securely positions the workpiece. Works synchronously with the drilling unit.
Mobile plates in the drilling area allow for through milling.
The centralized lubrication unit will allow you to timely service hard-to-reach units.
