Diamond router cutter P003 20x28x90x20 Z=3+3 Nesting HD (Taiwan) for cutting chipboard

All about product
Specification
Reviews
1
Information
Recommended
Articles
In Stock
Product code: 1042
Reviews: 1
225.00€
Buy in 1 click:
Specifications: (See all)
Cutting diameter, mm
20
Cutting height, mm
28
Total length, mm
90
Shank diameter, mm
20

Get AI analytics

Diamond router cutter P003 20x28x90x20 Z=3+3 Nesting HD (Taiwan) for cutting chipboard

Free chat with an experienced specialist

Feel free to contact us at any convenient time — we’re available from 9:00 to 4:00 PM

Description

Diamond router cutter P003 20x28x90x20 Z=3+3 Nesting HD (Taiwan) for cutting chipboard is used on CNC router machines for planing, cutting quarters, grooving, edging and cutting chipboard, MDF, laminated chipboard, laminate, plastics and veneered panels. High productivity is achieved with preliminary and finishing milling.

Diamond router cutter 3+3 HD (Taiwan) for cutting chipboard

Characteristics of the diamond cutter:

  • OL - 90 mm;
  • CL - 28 mm;
  • D - 20 mm;
  • d - 20 mm.

Peculiarities:

  1. Heavy duty steel housing to reduce vibration.
  2. 3 diamond (PCD) cutting edges.
  3. Resharpenable cutting edge.

hd diamond cutters



Specifications
Specifications
Cutting diameter, mm
20
Cutting height, mm
28
Total length, mm
90
Shank diameter, mm
20
Cutting part material
PCD
Number of cutting edges, pcs
3+3
Reviews
5 / 5
average product rating
1
0
0
0
0
Makar Malyi
Makar Malyi
16 october 2020 (12:13)
I have been working with such cutters for quite a long time and I can say that they fully meet the stated characteristics and my requirements. I process chipboard and MDF, I get about 200 sheets of chipboard before the first sharpening, as soon as I see chips I change it to processing MDF, and after that I send it to sharpening. I have 2 such cutters that I use alternately, the quality is excellent. Processing is carried out at a speed of 20-22 m/min.
