Sort By:
Workpiece width, mm: 35-1200
Workpiece length, mm: 70-2800
Width of blanks for grooving, mm: 50-850
Workpiece thickness, mm: 9-60
Workpiece gripper travel speed (X), m/min: 140
Control system: TPA (Italy)
Working area (X/Y/Z), mm: 3100x2150x230
Spindle: HSD, 13.2 kW, 24000 rpm, clamp HSK-63F
drilling head: 10 vertical spindles, 1.7 kW, 6000 rpm
Tool change: revolver for 16 places
Curvilinear edge banding machine KDT-305M for PUR/EVA adhesive
Product code: 3210
7 492.50€
Min. internal radius of the part, mm: 20
Table size, mm: 960x960
Feed speed, m/min: 1-10
Edge width, mm: 9-60
Total power, W: 2450
Curvilinear edge banding machine KDT-305MC with milling unit and vacuum clamping of the workpiece for PUR/EVA adhesive
Product code: 2351
11 520.00€
Min. internal radius of the part, mm: 20
Feed speed, m/min: 1-10 (automatic feed), 1-18 (manual feed)
Edge thickness, mm: 0.4-3
Edge width, mm: <14 (single-sided milling), 14-70 (top and bottom milling)
Max. round billet diameter, mm: 2700
Workpiece length, mm: 600-3200
Workpiece width, mm: 100-1000
Workpiece thickness, mm: 30-60
Horizontal processing depth, mm: 150
Maximum travel speed, m/min: 80
Workpiece width, mm: 35-1200
Workpiece length, mm: 70-2800
Workpiece thickness, mm: 9-60
Workpiece gripper travel speed (X), m/min: 140
Maximum speed along the axis (Y), m/min: 90
Control system: Delta (Taiwan)
Working area (X/Y/Z), mm: 3100x2150x100
Spindle: KDT, 12 kW, 24000 rpm, ISO-30 clamp
drilling head: 10 vertical spindles, 1.7 kW, 6000 rpm
Tool change: revolver for 12 places
Curvilinear edge banding machine KDT-305
Product code: 2014
3 780.00€
Min. internal radius of the part, mm: 20
Table size, mm: 960x960
Feed speed, m/min: 1-10
Edge width, mm: 9-60
Total power, W: 2450
Workpiece width X, mm: 250-2450
Workpiece width Y, mm: 100-935
Maximum workpiece thickness, mm: 70
Max. distance between extreme spindles horizontally, mm: 640
Max. distance between extreme spindles vertically, mm: 896
Workpiece width, mm: 35-1000
Workpiece length, mm: 70-2800
Workpiece thickness, mm: 9-60
Workpiece gripper travel speed (X), m/min: 140
Maximum speed along the axis (Y), m/min: 90
Maximum cutting length, mm: 2850
Maximum cutting width, mm: 2850
Minimum grip dimensions when sawing, mm: 34x45
Maximum cutting thickness, mm: 90
Saw carriage travel speed, m/min: 95
Drilling machine KDT-6462 (drilling from 4 sides)
Product code: 2021
Workpiece width X, mm: 250-3320
Workpiece width Y, mm: 100-935
Maximum workpiece thickness, mm: 70
Max. distance between extreme spindles horizontally, mm: 640
Max. distance between extreme spindles vertically, mm: 896
Edge banding machine KDT KE-710BT with full servo adjustment
Product code: KE-710BT
Feed speed, m/min: 15-24
Machine units: 1. Pre-milling. 2. Press group. 3. Trimming. 4. Milling unit. 5. Corner routing. 6. Profile scraper. 7. Glue scraper. 8. Polishing unit.
Minimum part size, mm: 120x90
Workpiece thickness, mm: 10-60
Edge thickness, mm: 0.4-3
Edge banding machine KDT KE-710BTC4 with full servo adjustment and edge magazine
Product code: KE-710BTC4
Feed speed, m/min: 15-24
Machine units: 1. Pre-milling. 2. Servo magazine for edge in 4 positions. 3. Press group. 4. Trimming. 5. Milling unit. 6. Corner routing. 7. Profile scraper. 8. Glue scraper. 9. Polishing unit.
Minimum part size, mm: 120x90
Workpiece thickness, mm: 10-60
Edge thickness, mm: 0.4-3
Loading table with label printing for nesting KHA-1710TS from KDT
Product code: 2067
Maximum workpiece size, mm: 3050x2135
Height of the package of blanks, mm: 500
Workpiece thickness, mm: 10-25
Load capacity, kg: 3500
Travel speed along the X/Y axes, m/min: 30/30
Workpiece width, mm: 35-1000
Workpiece length, mm: 70-2800
Workpiece thickness, mm: 9-60
Workpiece gripper travel speed (X), m/min: 140
Maximum speed along the axis (Y), m/min: 90
Workpiece width, mm: 35-1200
Workpiece length, mm: 70-2800
Workpiece thickness, mm: 9-60
Workpiece gripper travel speed (X), m/min: 140
Maximum speed along the axis (Y), m/min: 90
Feed speed, m/min: 8-12
Machine units: 1. Jointing. 2. Press group. 3. Trimming. 4. Milling for removal of overhangs. 5. Contouring (rounds). 6. Scraping with radius knives. 7. Scraping with straight knives. 8. Polishing.
Minimum part size, mm: 120x90
Workpiece thickness, mm: 9-60
Edge thickness, mm: 0.4-3
Unloading table KDT for nesting KHA-9710
Product code: 2006
Maximum workpiece size, mm: 3050x2100
Workpiece thickness, mm: 10-60
Total power, kW: 1.5
Table dimensions (LxWxH), mm: 3480x2525x926
Weight, kg: 650
Unloading table KDT for nesting KHA-9713
Product code: 2196
Maximum workpiece size, mm: 3050x2100
Workpiece thickness, mm: 10-60
Total power, kW: 1.5
Table dimensions (LxWxH), mm: 4455x2525x926
Weight, kg: 750
Cardboard width, mm: 200-2400
Cardboard thickness, mm: 2-11
Minimum reaming length, mm: 350
Productivity, boxes/min: 3-6
Number of preset templates, pcs: 40
Workpiece width, mm: 35-1200
Workpiece length, mm: 70-2800
Workpiece thickness, mm: 9-60
Workpiece gripper travel speed (X), m/min: 140
Maximum speed along the axis (Y), m/min: 90
